Innovators West: 2009-2015 LSX Camaro, GM 1999-2013 Trucks & 06-08 TBSS 8-Rib Harmonic Damper - 15% Overdrive
Vendor: Innovators West
SKU: 865
More info
SFI 18.1 Harmonic Damper for GM 2009-2015 LSX Gen 5 Camaro, GM 1999-2013 Trucks & 06-08 Trailblazer SS - w/ Crank Bolt. Features 8-Rib, 15% Overdrive Pulley. Complete 8 Rib Conversion Kits also available, see options below.
NOTE: Although this damper is designed with 8 belt grooves, it may be used with the stock 6-rib accessory drive with no issues.
Options
-
Dual Keyway Option - Add $20.00
Add dual keyways for Supercharged or Extreme Duty Applications. Requires double keyed crankshaft snout. -
LS Crank Pin Kit - Add $75.00
#968 Crankshaft Pin Kit for GM LS Trucks, TBSS and Gen 5 Camaro's. Designed for use with Innovators West dampers. For Stock Crankshafts Only. -
LSX Blower Hub Option - Add $25.00
The super duty hub has increased material for supercharged applications.This increased material helps to protect the hub from cracking in high load applications. The super duty hub is recommended for supercharged applications making over 750 rwhp. Includes matching timing cover oil seal.
Details
- Diameter: 8.35"
- Weight: 10.2 lbs
- Exceeds SFI 18.1 standards and is marked on front with SFI Sticker, and on the rear with SFI number stamped into unit.
Reference
- GM LSX Motors [PDF Format] .
- Damper Hub Honing Instructions [PDF Format] .
